ENGINE SPECIFICATIONS
Engine Displacement (cc), Engine Type 700, 4-Stroke, Twin Cylinder
Cooling System Liquid with Fan
Bore & Stroke (mm) 76.9x75.3
Alternator Capacity (amps) 36
Fuel Capacity gal. (liters) 7.4 (28)
SUSPENSION SPECIFICATIONS
Front Suspension / Travel in. (cm) Double A-Arm / 10 (25.4)
Rear Suspension / Travel in. (cm) Double A-Arm / 10.5 (26.7)
Ground Clearance in. (cm) 10 (25.4)
Shocks FOX Shocks
Front Tire / Size Carlisle Trail Pro / 25x8-12
Rear Tire / Size Carlisle Trail Pro / 25x10-12
Wheels Steel
POWERTRAIN SPECIFICATIONS
Transmission Rapid Response Clutch, Hi/Lo Range, Reverse and Park
Drive System 2/4 WD + Electronic Front Differential Lock
Brakes Front / Rear Hydraulic Disc
DIMENSIONS SPECIFICATIONS
Overall Size LxWxH in. (cm) 110.5x50x64.3 (280.7x127x163.3)
Wheelbase in. (cm) 84.6 (214.9)
Dry Weight lbs. (kg) 996 (451.7)
Front/Rear Rack or Box Capacity lbs. (kg) 300 (136.1)
Towing Capacity lbs. (kg) 1500 (680.4)
Hitch Type Rear 2" Receiver
